Metal Fabrication and Roll Forming Protection Film

Applying the Film

There are various ways the film can be applied to the substrate, but the metal surface must be clean and dry before applying the protective film. Remove any dust, oil, grease, or other contaminants that could interfere with adhesion.

Manual Application: This method is the optimal choice for small-quantity applications. Start by unrolling the film and positioning it precisely over the metal surface. Apply firm pressure with a squeegee or roller to ensure excellent adhesion and eliminate air bubbles. Finally, trim away excess film for a clean finish.

Automated Application: Ideal for high-volume applications and production. Automated applications will dramatically enhance speed, accuracy, and efficiency. Automated applications include film unwinders, tensioners, edge sealers, and application rollers.

Removing the Film

1. Prepare the Equipment and Work Area: Clean, non-abrasive cloths, a plastic or nylon scraper. Wear gloves and appropriate eye protection to prevent injury during handling.
2. Find a Starting Edge: Locate an accessible edge or seam in the protective film. Use a plastic scraper to gently lift a corner. Be especially careful on polished or precision-machined surfaces to avoid marring or introducing scratches.
3. Remove the Film Slowly: Begin peeling the film back with steady, even tension. Maintain a 45-degree angle and avoid sudden or forceful pulls. Do not yank, aggressive removal can cause the film to disperse dust into critical surface areas.
4. Final Surface Clean and Handling: Once the surface is clean, do a full wipe-down with a dry microfiber or lint-free cloth. This ensures no smudges or lint remain before packing, painting, or installation. If parts will be stored, rewrap or protect them appropriately.
